MM-Series Cloud-Managed Server with RAID
OE-MM-RAID-GEN-2

Product Overview

A cloud-managed server, the OE-MMXR supports up to 128 channels of video.

User Login
Sign in and get access to exclusive content. Don't have an account? Register now.

Support Downloads

Software

Command Station Software:
2.8.1.40

Documents

Quick Start Guide:
OE-MM Gen 2 Quick Start Guide
User Manual:
OE-MM Gen 2 Hardware Manual
User Manual:
OWS Apex Console & Thin Client Software Manual
Spec Sheet:
OE-MM Gen 2 Spec Sheet
Line Card:
Recorder and Camera Line Card
AE Spec:
OE-MM Gen 2 A&E Spec Sheet

Key Features

4 Drive Capacity 4 Drive Capacity
Dual GB NICs Dual GB NICs
Front Swappable Drives Front Swappable Drives
RAID 5 RAID 5
SSD OS Drive SSD OS Drive
Scalable NVR Server Scalable NVR Server

Technical Specs

Max Channel Count:
64 (128 w/ Upgrade Options)
Max Recording Rate:
400 Mbps
Max Storage Capacity:
48TB (36TB usable)
Operating System:
Windows
Network Ports:
1 x 2.5GbE, 1 x GbE
OS Drive:
Dedicated SSD
Power Consumption:
Max: 311W | Nominal: 241W
Dimensions:
W: 16.9” x H: 3.5 x D: 18”
Weight:
27lbs (12.25kg)
Country Of Origin:
United States

Accessories

External I/O Device
Part Number: OE-ZIO4EXT
MM Gen. 2 Performance Upgrade
Part Number: OE-ZPRFUPG-MM2
M-Series 16GB System Memory Upgrade
Part Number: OE-ZPRFUPRAM-16
M-Series Windows 10 OS to Windows 11 OS Upgrade - i7
Part Number: OE-ZW11UPG-I7
M-Series Windows 10 OS to Windows 11 OS Upgrade
Part Number: OE-ZW11UPG
