MK-Series Cloud-Managed Server with RAID
OE-MK-RAID-Gen-4

Product Overview

A purpose-built and enterprise server, the OE-MKXR supports 128 channels, and 96TB of redundant storage.

User Login
Sign in and get access to exclusive content. Don't have an account? Register now.

Support Downloads

Software

Apex Digital Signature Verifier:
1.7.0.0
Command Station Software:
2.8.1.40
Software Spot Monitor:
1.0.0.1003

Documents

Quick Start Guide:
OE-MK GEN 4 Quick Start Guide
User Manual:
OE-MK GEN 4 Hardware Manual
User Manual:
OWS Apex Console & Thin Client Software Manual
Spec Sheet:
OE-MK GEN 4 Spec Sheet
Line Card:
Recorder and Camera Line Card
AE Spec:
OE-MK GEN 4 A&E Spec Sheet

Key Features

8 Drive Capacity 8 Drive Capacity
Front Swappable Drives Front Swappable Drives
Rack Mountable Rack Mountable
RAID 1 OS RAID 1 OS
RAID 5 RAID 5

Technical Specs

Max Channel Count:
128
Max Recording Rate:
400 Mbps
Operating System:
Windows
Network Ports:
1 x 2.5GbE, 1 x GbE
Form Factor:
2U
OS Drive:
RAID 1 (2x M.2 NVMe SSD)
Storage Drives:
8
Max Storage Capacity:
96TB (84TB usable)
Power Supply:
500W
Power Consumption:
Max: 370W | Nominal: 267W
Dimensions:
W: 17.3" x H: 3.5" x D: 22" (438 x 87 x 557mm)
Weight:
38lbs (17.3kg)
Certifications:
ETL (Intertek) / FCC
Country Of Origin:
Assembled in the USA
NDAA Compliant:
Yes

Accessories

External I/O Device
Part Number: OE-ZIO4EXT
M-Series Windows 10 OS to Windows 11 OS Upgrade - i7
Part Number: OE-ZW11UPG-I7
